RANE FOUR – Advanced 4-Channel Stems DJ Controller


Advanced 4-Channel Stems DJ Controller

RANE FOUR Serato Stems DJ Controller

Advanced 4-channel controller designed for creative DJ performances with RANE’s industry-leading build-quality and signature sound
Harness the Power of Stems

Dedicated Instrumental and Acapella instant-access buttons, STEMS pad mode, and exclusive STEM-SPLIT feature lets you unleash the full creative power of Serato Stems.

New Levels of Creative FX

The newly designed internal FX suite with 22 paddle-triggered Main FX and 4 knob-controlled Channel FX adds additional flavor to individual Stem elements and tracks.

Four Channels of Performance Possibility

Four channel mixer section with 2 external line/phono inputs and enhanced Sampler routing plus quick-access jog wheel deck selection buttons for complete creative freedom.

Displays for Days

See vital information at a glance with the Performance Pad OLED screens, an industry first. The screens brightly display Cue, Loop, and Sample names, beat divisions, Scratch Bank slots, and Stems elements + FX.

RANE ONE – Professional Motorized DJ Controller

Designed with Serato for Superior Stems Control

RANE and Serato have a long history of creating groundbreaking DJ products together, dating back to the RANE SL1 box in 2004. The RANE FOUR takes this partnership to the next level by melding the industrial-grade build and sound quality of RANE hardware with the powerful new Stems capabilities of Serato DJ software. The result is a bullet-proof, feature-packed DJ controller with unprecedented Serato Stems creative control.

Introducing Stem-Split

With a single button press, the RANE FOUR instantly splits the Acapella and Instrumental of a track across two deck layers of the mixer section, allowing you to cut up vocal samples in real-time, add independent FX to each element, chop the track up with the Performance Pads, and more.

Dedicated Instrumental/Acapella Buttons

The dedicated Stems section lets you isolate or subtract the vocals or instruments of any track at any time with a quick button tap , and without leaving your currently selected Performance Pad mode. Perfect for live blends, remixes, and acapella-out-style mixing.

STEMS Performance Pad Mode

Isolate or remove vocals, melody, bass, and drums instantly with the STEMS Performance Pad mode. The bottom row of Performance Pads adds STEM FX to the mix when removing elements. Stem separation can be applied to any song and is processed in real-time.*

OLED Visual Pad Displays

The 8 displays above the Performance Pads on each deck offer visual feedback for all pad modes, making it easier than ever to see the function of each pad without having to look at the computer. See Cue, Loop, and Sample names as well as Roll and Loop lengths and beat divisions.

New Internal FX Suite with Dynamic Control Options

The RANE FOUR features a powerful dedicated internal FX engine with 22 MAIN FX including tried and true classics like Reverb and Echo and new additions including Scale Down, Recycler, Riser, and more. The Channel FX section offers dynamic, hands-on manipulation of 4 knob-controlled FX including Filter, Filter Roll, Noise, and Flanger. The RANE FOUR also allows you to switch seamless back and forth between the built-in hardware FX and Serato’s software FX, providing limitless options for any style of DJing.

Full Size High-Resolution Jog Wheels

The 8.5” capacitive jog wheels were designed to be the smoothest and most accurate static jog wheels available on a DJ controller. A central color display indicates play head position, BPM, pitch percentage, pitch range, overview waveform with Hot Cue markers, song key, time, loop size, deck selection, Beat Jump length and more

Trusted RANE Quality

The RANE FOUR is the only 4-channel DJ controller built to RANE’s rigorous standards. Solid, bulletproof construction, MAG-FOUR crossfader, aluminum FX toggles, and industry-leading sound quality and connections ensure that the RANE FOUR will always perform like a champ, no matter what.

*Performance will vary based on computer specifications. Visit the Serato website for full details.

Tech Specs

Digital Audio
  • Converters: Cirrus Logic, 24-bit PCM, 48 kHz
  • Digital Signal Processing: 32-bit, Floating Point, Double precisio
  • Dynamic Range (A-weighted, unity gain):
    • ADC: 113 dB
    • DAC: 113 dB
    • CD Input to Analog Output: 110 dB
    • CD Input to USB Output: 113 dB
    • USB Input to Analog Output: 113 dB
  • Microphone 1/2 (Combo XLR/1/4" [6.35 mm] TRS):
    • Analog Gain: 25 dB
    • Maximum Input: 110 mV
    • Gain Trim: Off to +26 dB (unity at center)
    • Tone Control: 2-band
  • Line/Phono Inputs 3/4 (RCA stereo pairs, switchable):
    • Line: Line
    • Maximum Input: 4 Vrms
    • Gain Trim: Off to +12 dB
    • Tone Control: 3-band, full-cut to +10 dB
    • THD+N (20 kHz BW @ 1 kHz: 0.004%
    • Phono: RIAA
    • RIAA Curve: +/-0.25 dB
    • Gain (@ 1 kHz): 31.5 dB
    • Maximum Input (@ 1 kHz): 106 mV
    • Dynamic Range (A-weighted): 102 dB
  • Main Outputs (XLR):
    • Gain Trim: Off to 0 dB
    • Maximum Output: 8 Vrms
    • THD+N (20 kHz BW @ 1 kHz): 0.004%
    • Frequency Response: Flat - 20-20kHz
  • Main Outputs (RCA stereo pair):
    • Maximum Output: 4 Vrms
    • THD+N (20 kHz BW @ 1 kHz): 0.004%
    • Frequency Response: Flat - 20-20kHz
  • Booth Outputs (1/4”):
    • Gain Trim: Off to 0 dB
    • Maximum Output: 8 Vrms
    • THD+N (20 kHz BW @ 1 kHz): 0.004%
    • Frequency Response: Flat - 20-20kHz
  • Headphone Outputs (1/4"/6.35 mm and 1/8"/3.5 mm TRS):
    • Maximum Output: 4 Vrms Voltage: (no load)
    • Output Power: 50 mW (50 ohms)
    • Dynamic Range (A-weighted): 108 dB
  • (16) on/off multi-color back-lit pads (8 per deck, 9 modes each
Wheel Displays
  • (2) 320 x 240 Color LCD’s
Pad & FX Displays
  • (9) 128 x 32 Monochrome OLED’s
  • (1) MAG FOUR tension-adjustable crossfader with contour
  • (4) Standard channel faders
  • (2) XLR outputs (Main)
  • (2) 1/4” outputs (Booth)
  • (1) RCA stereo output pair (Main)
  • (2) XLR / 1/4” (6.35 mm) TRS inputs (Mic 1–2)
  • (2) RCA stereo input pairs (Deck 3-4)
  • (1) 1/4” (6.35 mm) TRS output (Headphones)
  • (1) 1/8” (3.5 mm) TRS output (Headphones)
  • (2) USB Type-B ports
  • (1) IEC power cable input
  • Connection: IEC
  • Voltage: 100–240 V, 50/60 Hz
  • Consumption: 20 W
  • Dimensions (width x depth x height): 30.8” x 15.9” x 4.2”
    782.32 x 403.8 x 106.6 mm
Weight (including platters)
  • 18.25 lbs.
    8.27 kg
